Hikvision DS-7208HGHI-M1 8 Channel 720p 1U H.265 Digital Video Recorder
Hikvision DS-7208HGHI-M1 8 Channel 720p 1U H.265 Digital Video Recorder
Key Features
-
Motion Detection 2.0
Human/Vehicle Analysis
Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights;
Quick search by object or event type is supported;
Recording
- Video Compression
- Encoding Resolution
For 720p stream access: 720p/WD1/4CIF/VGA/CIF
For SD stream access: WD1/4CIF/VGA/CIF
- Frame Rate
For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF@15 fps
For 720p stream access: 720p/WD1/4CIF/VGA/CIF@15 fps
For SD stream access: WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)
Sub-stream:
For 1080p and 720p stream access CIF/QVGA@15 fps
For SD stream access: CIF/QVGA@25 fps (P)/30 fps (N)
- Video Bitrate
Stream Type
Video, Video & Audio
- Audio Compression
- Audio Bitrate
- Video And Audio
2-ch (up to 10-ch)
- Up to 5 MP resolution
Analog Video Input
8-channel
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
- HDTVI Input
- AHD Input
- HDCVI Input
CVBS Input
Support
- HDMI Output
VGA Output
1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
Video Output Mode
HDMI/VGA simultaneous output
Audio Input
1-ch RCA (2.0 Vp-p, 1 KΩ)
8-ch via coaxial cable
Audio Output
1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio
Reuse the first audio input
Synchronous Playback
8-ch
- Network
64
- Network Protocol
Total Bandwidth
72 Mbps
- Network Interface
- Auxiliary Interface
1 SATA interface
Capacity
Up to 4 TB capacity for each disk
USB Interface
Rear panel: 2 × USB 2.0
Alarm In/Out
N/A
- General
12 VDC, 1.5 A
Consumption
≤ 17 W (without HDD)
Working Temperature
-10 °C to 55 °C (14 °F to +31 °F)
Working Humidity
10% to 90%
Dimension (W × D × H)
260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch)
Weight
≤ 1 kg (without HDD, 2.2 lb.)
6,599.00 KSh
6,599.00 KSh
